Description

TRONIC Automatic Transfer Switch (ATS) controller uses microprocessor as its core which can precisely monitor voltage (loss of main power). The ATS will start functioning in the following circumstances; loss of power, over voltage, under voltage phase.
Additional Information
Colour White
Amps 150A
Voltage AC 230V±30%
Material Aluminium
Additional Information
DC power supply: DC(8-35)V between VIN and GND
Measured voltage: Rated line voltage 400V; 50Hz/60Hz: 3 phase 4 wire.
Range of abnormal power
Over voltage threshold: 240~290, 5V. Default: 264 5V.
Under voltage threshold: 164~198V, 5V. Default: 172 5V
Voltage normal delay: (1~60) seconds.
Voltage abnormal delay: (1~60) seconds, default: 5 seconds.
Genset start delay: Issued at a default of 5 seconds.
Genset start delay: Is set at default 60 seconds.
Envoirment conditions:
Working Temperature: (-30~+70) C.
Humidity: (20~95)%RH.
Warranty 1 Year
